Placa Mae Gigabyte Amd (Am5) Micro Atx Ddr5 - B850m A Elt Wf6e

________________________________________
CPU
•     AMD Socket AM5
•     Suporte para:
o     AMD Ryzen™ 9000 Series
o     AMD Ryzen™ 8000 Series
o     AMD Ryzen™ 7000 Series
•     Consulte o site da Gigabyte para a lista completa de CPUs compatíveis
________________________________________
Chipset
•     AMD B850
________________________________________
Memória
•     Suporte para módulos DDR5:
o     8200(O.C), 8000(O.C), 7950(O.C), 7900(O.C), 7800(O.C), 7600(O.C),
7400(O.C), 7200(O.C), 7000(O.C), 6800(O.C), 6600(O.C), 6400(O.C),
6200(O.C), 6000(O.C), 5800(O.C), 5600(O.C), 5200, 4800, 4400 MT/s
•     4× slots DDR5 DIMM, até 256 GB (64 GB por slot)
•     Arquitetura dual-channel
•     Suporte para memórias non-ECC un-buffered 1Rx8 / 2Rx8 / 1Rx16
•     Suporte para AMD EXPO™ e Intel XMP
________________________________________
Gráficos Integrados
•     Processador gráfico integrado AMD Radeon™ (dependente da CPU)
•     1× DisplayPort 1.4 — até 3840×2160 @ 144 Hz, HDR
•     1× HDMI 1.4 (frontal) — até 1920×1080 @ 30 Hz
________________________________________
Áudio
Rev. 1.0
•     Realtek® Audio CODEC
•     Áudio HD 2/4/5.1/7.1 canais
•     Suporte a S/PDIF Out
Rev. 1.1
•     Realtek® ALC1220
•     Áudio HD 2/4/5.1/7.1 canais
•     Suporte a S/PDIF Out
•     Suporte a DSD no conector de saída traseira
________________________________________
Rede
LAN
•     Realtek® 2.5GbE — 2.5 Gbps / 1 Gbps / 100 Mbps
Wi-Fi / Bluetooth
•     Realtek® Wi-Fi 6E RTL8852CE
•     Wi-Fi: 802.11 a/b/g/n/ac/ax (2.4 / 5 / 6 GHz)
•     Bluetooth® 5.3
•     Suporte 160 MHz (11ax)
________________________________________
Slots de Expansão
•     1× PCIe x16 (da CPU)
o     Ryzen 9000/7000 ? PCIe 5.0 x16
o     Ryzen 8000 Phoenix 1 ? PCIe 4.0 x8
o     Ryzen 8000 Phoenix 2 ? PCIe 4.0 x4
o     Aceita somente GPU ou SSD NVMe
•     1× PCIe x16 (chipset)
o     PCIe 3.0 x4
________________________________________
Armazenamento
M.2
•     M2A_CPU (PCIe 5.0/4.0)
o     Suporte a SSDs 25110/22110/2580/2280
•     M2B_CPU (PCIe 4.0)
o     Suporte a SSDs 22110/2280
SATA
•     4× portas SATA 6 Gb/s
RAID
•     NVMe: RAID 0/1/5*/10 (*RAID 5 apenas com Ryzen 9000)
•     SATA: RAID 0/1/10
________________________________________
USB
Traseira
•     1× USB-C 3.2 Gen 2
•     2× USB-A 3.2 Gen 2 (vermelho)
•     5× USB 3.2 Gen 1
•     4× USB 2.0
Interna
•     1× USB-C 3.2 Gen 2x2 (via header)
•     2× USB 3.2 Gen 1
•     4× USB 2.0
________________________________________
Conectores Internos
•     1× Conector ATX 24 pinos
•     1× Conector ATX 12V 8 pinos
•     1× Header de ventilador CPU
•     1× Header bomba de água/CPU
•     3× Headers de ventoinha
•     1× Header de bomba/ventoinha adicional
•     3× Headers ARGB Gen2
•     1× Header RGB
•     2× M.2 (Socket 3)
•     4× SATA 6Gb/s
•     1× Header painel frontal
•     1× Áudio frontal
•     1× Header USB-C
•     1× Header USB 3.2 Gen 1
•     2× Headers USB 2.0
•     1× Header TPM
•     1× HDMI (nota: suporte depende da CPU)
•     1× Botão Reset
•     1× Jumper Reset
•     1× Jumper Clear CMOS
________________________________________
Painel Traseiro
•     1× DisplayPort (dependente da CPU)
•     1× Botão Q-Flash Plus
•     4× USB 2.0
•     5× USB 3.2 Gen 1
•     2× USB 3.2 Gen 2
•     1× USB-C 3.2 Gen 2
•     1× RJ-45 2.5GbE
•     2× Conectores de antena Wi-Fi
•     2× Jacks de áudio
•     1× Saída óptica S/PDIF
________________________________________
BIOS
•     256 Mbit Flash
•     BIOS AMI UEFI com suporte:
o     PnP 1.0a
o     DMI 2.7
o     WfM 2.0
o     SM BIOS 2.7
o     ACPI 5.0
________________________________________
Recursos Exclusivos
•     Gigabyte Control Center
•     Q-Flash
•     Q-Flash Plus
•     Smart Backup
________________________________________
Software Incluso
•     Norton Internet Security (OEM)
•     Software de gerenciamento de banda LAN
________________________________________
Sistema Operacional Compatível
•     Windows 11 64 bits
•     Windows 10 64 bits
________________________________________
Formato
•     Micro ATX — 24,4 × 24,4 cm
________________________________________
